System: COMFORT Material : Fe/Zn Standard : - Note : Metallic arc insert to FV THERM TBS system mat. For heating pipes with 14mm diameter.

System: COMFORT Material : EPS/PS Standard : EN 13163 Note : Combined thermal and sound insulation of EPS 30 mm with a layer resistant to deep-drawn PS foil formed into the shape of studs. A suitable mat for heating pipes with diameters of 16–18 mm, with a rim for easy connection to other mats. System mat for fl oor heating allows quick and easy installation with minimum of pruning.   1400 × 800 × 30 mm pcs 8 1,75 57,08 AA902001030 16–18 mm 50 1,12 5 0,035

System: COMFORT Material : EPS/PS Standard : EN 13163 Note : Combined thermal and sound insulation of EPS 11 mm with a layer resistant to deep-drawn PS foil formed into the shape of studs. A suitable mat for heating pipes with diameters of 16, 17 and 18 mm, with a rim for easy connection to other mats. System mat for fl oor heating allows quick and easy installation with minimum of pruning. # for Ø D pitch [mm] netto area [m²/ks] load capacity [kN/m²] thermal conductivity [W/m.K] 1400 × 800 × 11 mm pcs 14 1,286 31,875 AA902002011 16–18 50/70 1,12 4,6 0,035

System: COMFORT Material : PS Standard : EN 13163 Note : Universal mat of durable PS fi lm with studs. For heating pipes with diameters 14–18 mm. Enables 38 mm or 75 mm spacing. Special rim for easy connection of mats.  1470 × 870 × 21 mm pcs 14 1,286 16,56 AA902002000 14–17 60/84 1,20 unlimited 1400 × 800 × 21 mm pcs 180 0,975 10,92 AA902003000 16–18 50/70 1,12 unlimited

System: COMFORT Material : PS Standard : EN 13163 Note : Universal mat of durable PS fi lm with studs. For heating pipes with diameters 14–20 mm. Enables 38 mm or 75 mm spacing. Special rim for easy connection of mats.

System: COMFORT Material : EPS Standard : EN 13163 Note : Heat and sound insulation EPS base (according to DIN EN 13163) (WLS 045) with a grid patterned durable waterproof polyethylene membrane to prevent water and humidity leak. Grid enables easy pipe fi xing with tacker staples.

System: COMFORT Material : PE-RT/EVOH/PE-RT Standard : EN ISO 22391, DIN 4726 Note : Five-layer, highly fl exible polyethylene pipe PE-RT II with high heat resistance (acc. to EN ISO 22391), with an oxygen barrier of ethylene vinyl alcohol (EVOH) according to DIN 4726. Tmax 95°C.  8 × 1,0 m 200 foil 0,06 0,60 AA120008200 8 1,0 200 8 × 1,0 m 400 foil 0,06 0,60 AA120008400 8 1,0 400 10 × 1,3 m 200 foil 0,06 0,60 AA120010200 10 1,3 200 10 × 1,3 m 400 foil 0,06 0,60 AA120010400 10 1,3 400 12 × 1,5 m 200 foil 0,07 0,60 AA120012200 12 1,5 200 12 × 1,5 m 400 foil 0,07 0,60 AA120012400 12 1,5 400 14 × 1,8 m 200 foil 0,07 0,60 AA120014200 14 1,8 200 14 × 1,8 m 400 foil 0,07 0,60 AA120014400 14 1,8 400 15 × 1,8 m 200 foil 0,08 0,60 AA120015200 15 1,8 200 15 × 1,8 m 400 foil 0,08 0,60 AA120015400 15 1,8 400 16 × 2,0 m 200 foil 0,09 0,60 AA120016200 16 2,0 200 16 × 2,0 m 400 foil 0,09 0,60 AA120016400 16 2,0 400 17 × 2,0 m 200 foil 0,102 0,60 AA120017200 17 2,0 200 17 × 2,0 m 400 foil 0,102 0,60 AA120017400 17 2,0 400 18 × 2,0 m 200 foil 0,108 0,60 AA120018200 18 2,0 200 18 × 2,0 m 400 foil 0,108 0,60 AA120018400 18 2,0 400 20 × 2,0 m 200 foil 0,117 0,60 AA120020200 20 2,0 200

System: AQUA Material : PP-R Standard : - Note : Plastic clip with stirrup for sliding point of parallel pipe on the wall and ceiling.15 pcs 200 50 0,02 0,06 AA977015002 WA977015002 61,2 33,5 16,0 22,5 36,2 18 pcs 300 50 0,02 0,06 AA977018002 WA977018002 70,2 36,5 16,0 24,0 42,2 20 pcs 300 50 0,04 0,08 AA977020002 WA977020002 76,2 38,0 16,0 25,0 45,2 22 pcs 300 50 0,04 0,08 AA977022002 WA977022002 81,2 40,5 16,0 26,0 48,2 25 pcs 150 50 0,04 0,08 AA977025002 WA977025002 90,2 43,5 16,0 28,0 55,2

System: AQUA Material : PP-R Standard : - Note : Plastic clip with stirrup for sliding point of pipe on the wall and ceiling.  15 pcs 600 50 0,01 0,03 AA977015001 WA977015001 25,0 33,5 16,0 22,5 16 pcs 600 50 0,01 0,03 AA977016001 WA977016001 26,0 34,0 16,0 23,0 18 pcs 600 50 0,01 0,03 AA977018001 WA977018001 28,0 36,5 16,0 24,0 20 pcs 400 50 0,02 0,04 AA977020001 WA977020001 31,0 38,0 16,0 25,0 22 pcs 400 50 0,02 0,04 AA977022001 WA977022001 33,0 40,5 16,0 26,0 25 pcs 400 50 0,02 0,04 AA977025001 WA977025001 35,0 43,5 16,0 28,0

System: AQUA Material : PP-R Standard : - Note : Plastic clip for sliding point of parallel pipe on the wall. 2 × 16 pcs 500 50 0,01 0,04 AA976016002 WA976016002 65,3 30,2 15,9 24,2 40,4 2 × 20 pcs 450 50 0,02 0,05 AA976020002 WA976020002 70,5 34,8 15,9 25,5 43,4 2 × 25 pcs 200 50 0,03 0,06 AA976025002 WA976025002 89,0 40,0 15,8 27,8 54,7

System: AQUA Material : PP-R Standard : - Note : Plastic clip for sliding point of pipe on the wall.

System: AQUA Material : teflon Standard : - Note : Tape for sealing of fi ttings with metal thread
